Inconel X-750 is a nickel-chromium alloy similar to Alloy 600, but with the addition of aluminum and titanium elements for precipitation hardening. It features good corrosion resistance and oxidation resistance. X-750 maintains good creep fracture resistance in working environments up to 700°C. Its relaxation strength makes it suitable for manufacturing high-temperature springs and bolts. It is used in gas turbines, rocket engines, nuclear reactors, pressure vessels, mold forming, and aerospace structural components. chemical composition   Ni Cr C Mn Cu Si S Fe MIN 70.00 14.00           5.00 MAX -- 17.00 0.08 1.00 0.50 0.50 0.01 9.00 Material Standards: - AMS 5542 - AMS 5598 - AMS 5670 - AMS 5671 - ISO 15156-3 - NACE MR0175 Physical Properties: - Density: 0.299 lb/in³ - Melting range: 2540 - 2600°F - Poisson's ratio: 0.30 - Resistivity: 731 Ohm-circ mil/ft

Inconel 718 alloy is a precipitation-hardened nickel-chromium-iron alloy containing niobium and molybdenum. It exhibits high strength and good toughness at 700°C, as well as corrosion resistance in both high and low temperature environments. It can be supplied in either a solution-treated or precipitation-hardened condition.   chemical composition Category C Cr Ni Co Mo Al Ti Fe Standard 0.08 17.0~21.0 50.0~55.0 ≤1.0 2.80~3.30 0.30~0.70 0.75~1.15 Balance Category Nb Mg Mn Si P S Cu   Standard 4.75~5.50 0.01 0.35 0.35   0.015   0.015 0.3   Performance Melting temperature range 1260~1320 ℃, density p=8.24g/cm3 Linear expansion coefficient 8/℃ 20～100 20~200 20~30 20~400 20~500 20～600 20~700 20~800 20~900 20～1000 a/10-6'℃ 11.8 13 13.5 14.1 14.4 14.8 15.4 17 18.4 18.7   Scope of application Due to its high temperature strength, excellent corrosion resistance, and ease of processing at 700 ℃, Inconel718 alloy can be widely used in various high demand situations. 1. Steam turbine 2. Liquid fuel rocket 3. Low temperature engineering 4. Acidic environment 5. Nuclear engineering

Inconel 617 alloy exhibits excellent corrosion resistance in thermal corrosion environments such as sulfidizing conditions, particularly in cyclic oxidation and carburization environments up to 1100°C. These corrosion resistance properties, coupled with outstanding mechanical properties, make this alloy especially suitable for high-temperature applications. Inconel 617 is a nickel-chromium-cobalt-molybdenum alloy with excellent mechanical properties at high temperatures and resistance to high-temperature corrosion phenomena, such as oxidation and carburization. Characteristics of Inconel 617 include: - Excellent transient and long-term mechanical properties at temperatures up to 1100°C. - High resistance to oxidation at 1100°C. - High resistance to carburization at 1100°C. - Good weldability. Corresponding grades American standard German standard N06617 2.4663A chemical composition % Ni Cr Co Mo Fe C Mn Si S Al Ti Cu B Min 44.5 20 10 8 一 一 一 一   0.8   一   Max   24 15 10 3 0.05 1 1 0.015 1.5 0.6 0.5 0.006 physical property density melting point 8.36g/cm= 1330~1375℃ Inconel 617 Applications: Inconel 617 is suitable for high temperature and high mechanical stress environments. It is recommended for use at temperatures not exceeding 1000°C. Inconel 617 is also suitable for applications requiring weight reduction, such as processing of thin-walled structural components. ● Industrial and aviation turbine parts ● Air heaters ● Muffle furnaces and radiation galleries ● High-temperature heat exchangers, valves, and springs ● High-temperature gas-cooled nuclear reactors, such as high-temperature components in nuclear reactors - helium/helium medium heat exchangers ● Chemical processing equipment ● Spiral tubing and piping in the petrochemical industry

Inconel 625 is a Ni-Cr-based solid solution strengthened superalloy primarily reinforced with molybdenum and niobium. It maintains excellent tensile and fatigue properties from low temperatures up to 980°C and has an operational limit up to 950°C. The alloy is characterized by good processability and weldability, exceptional corrosion resistance and oxidation resistance, and it also shows resistance to stress corrosion in salt spray atmospheres.   The corresponding Grade for Inconel 625   China Standard American ASTM Germany DIN Japan JIS NS3306 N06625 2.4856 NCF625 NS336 Incone1625 NiCr22Mo9Nb   GH625       chemical composition % C Si Mn F S Ni Cr Mo Fe Al Ti Nb Co Cu Min 0.1 0.5 0.5 0.015 0.015 banlance 20 8 5.0 ≤0.4 0.4 3.15 1.0 ≤0.07 Max 一 一 一 一 一 一 23 10 一 一 一 4.15         The application fields of Inconel 625 alloy are broad due to its excellent corrosion resistance, oxidation resistance, and mechanical properties. It is particularly well-suited for environments that require high mechanical performance and contact with seawater. Common uses include gas turbine engines, nuclear power equipment, and aerospace engines.

Inconel 601 chemical composition：   Alloy % N Cr Fe C Mn Si Cu Al Ti B   601 Min 58 21           1.0     Max 63 25 Balance 0.1 1.5 0.5 1 1.7 0.02 0.015 Inconel 601 physical property ：   density 8.1 g/cm3 melting point 1320-1370℃ Minimum mechanical properties of Inconel 601 alloy at room temperature:     Alloy and state tensile strength Rm N/mm2 yield strength RP0.2N/mm2 Elongation rate A5 % Brinell hardness HB Annealing treatment 650 300 30   Solid solution treatment 600 240 30 ≤220   This alloy exhibits the following characteristics: 1. Excellent oxidation resistance at high temperatures. 2. Good resistance to carburization. 3. Effective resistance against sulfur-bearing atmospheres. 4. Excellent mechanical properties at both room and elevated temperatures. 5. Good resistance to stress corrosion cracking due to controlled carbon content and grain size; thus, Alloy 601 is recommended for use above 500°C.   Microstructure of Inconel 601: Alloy 601 has a face-centered cubic crystal structure.   Corrosion Resistance of Inconel 601: A significant feature of Alloy 601 is its oxidation resistance up to temperatures of 1180°C. Even under severe conditions, such as heating and cooling cycles, 601 can form a dense oxide layer which provides high resistance to spalling. Alloy 601 also exhibits good carburization resistance. Due to its high chromium and aluminum content, it has excellent oxidation resistance in high-temperature sulfur-containing atmospheres.   Applications of Inconel 601 include: 1. Trays, baskets, and fixtures used in heat treatment plants. 2. Components such as strand annealing and radiant tubes, high-speed gas burners, and wire mesh belts in industrial furnaces. 3. Isolation tanks in ammonia reforming and catalyst support grids in nitric acid production. 4. Components of exhaust systems. 5. Combustion chambers in solid waste incinerators. 6. Supports for piping and parts for ash handling. 7. Components of waste gas detoxification systems. 8. Oxygen preheaters.

Inconel 600 alloy is a nickel-chromium-iron-based solid solution strengthened alloy, known for its excellent high-temperature corrosion resistance and oxidation resistance, superb cold and hot processing and welding properties, as well as satisfactory thermal strength and high plasticity below 700°C. Applications ● Thermocouple sheaths in erosive atmospheres. ● Vinyl chloride monomer production: Resistant to chlorine gas, hydrogen chloride, oxidation, and carburization corrosion. ● Conversion of uranium oxide to hexafluoride: Resistant to hydrofluoric acid corrosion. ● Production and use of corrosive alkali metals, especially in environments involving sulfides. ● Production of titanium dioxide via the chlorine method. ● Production of organic or inorganic chlorides and fluorides: Resistant to chlorine and fluorine gas corrosion. ● Nuclear reactors. ● Retorts and components in heat-treatment furnaces, especially in carburizing and nitriding atmospheres. ● In petrochemical production, the use of Alloy 600H is recommended for catalytic regenerators operating above 700°C to achieve a longer lifespan. 2. Chemical Composition   N Cr Fe C Mn Si Cu Al Ti B P S Min. 72 14 6.0                   Max.   17 10.0 0.15 1.0 0.5 0.5 一 一     0.015 3. Equivalent Grades: GH3600, GH600 (China) NC15Fe (France) W. Nr. 2.4816 NiCr15Fe (Germany) NA14 (United Kingdom) Inconel 600, UNS NO6600 (USA) NiCr15Fe8 (ISO) Standards for Inconel 600: UNS N06600 DIN/EN 2.4816 ASTM B168 ASME SB-168 AMS 5540 NCF 600 Welding Inconel 600 is suitable for any traditional welding process, whether welding with similar materials or other metals. These processes include Tungsten Inert Gas (TIG) welding, Plasma Arc Welding, Submerged Arc Welding, Metal Inert Gas (MIG) welding, and Flux-Cored Arc Welding, with pulse arc welding being the preferred method. For manual arc welding, it is recommended to use a mixed shielding gas composed of Argon, Helium, Hydrogen, and Carbon Dioxide (Ar+He+H2+CO2).   The welding of Incoloy 825 must be performed in the annealed condition, and surfaces should be thoroughly cleaned with a stainless steel wire brush to remove stains, dust, and any markings. When welding at the root of the weld, great care must be taken to achieve optimal root weld quality using very high purity argon gas (99.99%) to prevent oxidation. Any discoloration in the heat-affected zone of the weld should be brushed off with a stainless steel brush before the weld area cools to remove heat tints.
